Liuto forte in d (“Bach-Lute”)

Repertory: all lute compositions of Johann Sebastian Bach in their reconstructed original version, all compositions for d minor lute from 1630 to 1800 (taking into account the extended tuning of the Bach lute), music of the 19th to 21st century, accompaniment of the two arias in St. John’s and St. Matthew’s Passions

14-stringed: Basic Tuning:
A B flat C D E F G A B flat d f a d‘ f‘

String-disposition: 12 fingerboard strings and 2 bourdon strings
(BWV 996, 999, 1000 and 1006a and two Passion Arias)

16-stringed: Basic Tuning:
E (or D flat) A B flat C D E flat F G A B flat c d f a d‘ f‘

String-disposition: 10 fingerboard strings and 6 bourdon strings
(BWV 995, 997, 998)

The string-disposition of the 14-string instrument can also be realized on the 16-string instrument, as it has 12 pegs in the first pegbox and 6 pegs in the second pegbox. The basic tuning of the 14-string instrument can also be realized on the 16-string instrument by changing strings or scordatura.

  • String-length: fingerboard strings 59 cm, String-length bourdon strings 84 cm
  • a’ = 440 Hz
  • Single stringing
  • Slightly curved fingerboard
  • 16 fixed frets (tied-on if desired)
  • One rose, broad body, 15 ribs
  • Traditional or geared pegs

Johann Sebastian Bach’s lute compositions

Discussion about Johann Sebastian Bach’s lute compositions began in 1901 with an essay by Wilhelm Tappert on these works, which until then had received little attention. Since that time, a number of theories have emerged, essentially all based on the assumption that these pieces were written for the same lute model with the same stringing and tuning as was used by Sylvius Leopold Weiß and his students.

This assumption was wrong and can be refuted by the compositions themselves.

The solution to the problem was made particularly difficult by the fact that Bach’s lute works are not handed down in tablature, but exclusively in sheet music. In two cases (Suite in G minor BWV 995 and Prelude, Fugue and Allegro in E-flat Major BWV 998), these are even manuscripts from Bach’s own hand, whose titles expressly mention the lute as the executing instrument.

Additional confusion was caused by three manuscripts of the 18th century, which contained intabulations of three lute compositions by Johann Sebastian Bach (BWV 995, 997 and 1000) for the most common lute model of the time with 13 courses in the basic tuning Aa-Bb-Cc-Dd-Ee-Ff-Gg-Aa-dd-ff-aa-d’-f’. These arrangements, however, contain substantial changes to the surviving musical text of these works and, in the case of the Suite in G minor BWV 995, do not even do justice to the extent of this composition down to Kontra G as unmistakably demanded in Bach’s manuscript.

Instead of considering the possibility that J.S. Bach’s lute pieces might have been composed for a differently tuned and stringed lute model of the time, most of today’s players and musicologists tried to explain this obvious discrepancy by saying that these pieces might not have been written for the lute at all, but for the lute harpsichord – a gut-stringed keyboard instrument – which would allow seemingly unplayable notes to be played without difficulty. Others took the above-mentioned contemporary arrangements of these pieces for a 13-course lute as an opportunity to conclude that Bach was not at all concerned that a performance of these works was faithful to the score, that he wrote only “ideal” music and then left it up to the players to decide which notes they would like to omit or shift by an octave.

Another direction of discussion, which also did not lead to useful results, was the question of whether Bach was a lutenist. This question was of about the same value as that of whether he was a cellist or a flute player, since he left compositions for these instruments.

Bach possessed – among other keyboard instruments – a lute harpsichord as well as a lute whose value in his estate was estimated at 21 talers.

The question should therefore rather have been how this lute model in his possession was tuned and strung in order to be able to reproduce his lute compositions faithfully on it.

The only proof that Bach’s pieces were actually intended for lute is to show how these pieces could be played on a different lute model of the time, or in other words, to reconstruct the path of his hands on the instrument with the greatest possible accuracy. I have dedicated many years of my life to this task.

The results of my efforts to answer this question are only briefly summarized here:

Bach’s lute compositions are indeed written for a lute model of his time, whose tuning from the sixth string on, however, deviated slightly from the traditional tuning and – like the Angélique – was entirely strung with single strings. Bach’s lute may probably even exist today, which will be discussed after some more dedicated research in due course.

On this lute, all of Johann Sebastian Bach’s lute compositions can be played not only absolutely correctly, but also completely naturally. The perfectly logical technical structure of their execution is in no way inferior to the perfection of this music. It is an unequivocal proof that Bach – who was not a professional lutenist – designed his pieces for lute on the instrument and examined each individual bar for its practical feasibility on the instrument. This perfect, technical playing structure leaves no doubt about it, that he first fixed these pieces in French tablature. His own subsequent transcription into staff notation apparently served to reproduce these works on his keyboard instruments, since the busy man probably lacked practical practice in lute playing.

Johann Sebastian Bach’s lute

What was Johann Sebastian Bach’s lute like?

The size, tuning and stringing of Johann Sebastian Bach’s lute can certainly be deduced from his works for this instrument.

The fingering structures of the right hand are partly atypical for an instrument with double strings. They are, however, to be found at every turn in tablatures for an instrument that was quite common at the time, with 16 individual strings: the Angélique. The overstretching of the left hand in Bach’s lute pieces, on the other hand, suggests a fingerboard scale that was barely more than 60 cm or even slightly less.

The tuning of the first 5 strings corresponds to the traditional D minor tuning of this period. The sixth string, however, is tuned to B flat in BWV 996 BWV1000 and the accompaniment of the two Passion arias, and to C in BWV 997, 998, 995 and 999. The suite in E major BWV 1006a requires the scordatura H – cis – e – a – cis’ – e’ for the upper playing strings, as was often used in 17th and 18th century lute music as well as in the violin repertory of this time (Heinrich Ignaz Biber).

Bach’s works for the lute were composed over a period of about 45 years. Two periods can be distinguished:

In the first period his instrument had 12 single strings on the fingerboard (lowest stopped note is C sharp) and two bourdon strings. In the second (after 1728) 10 individual strings on the fingerboard (lowest note played is F sharp) and 6 bourdon strings. This is the classical string disposition of an Angelique and suggests the assumption that the pegbox on Bach’s lute around 1728 underwent a rebuild.

The fingerboard of an Angelique designed for only 10 fingerboard strings would, however, be too narrow for the 12 single strings required for Bach’s lute compositions of the first period. The same applies to the double head lute, whose pegbox construction and neck width would allow a maximum of 8-9 fingerboard strings.

The only lute model existing at that time that had a neck width that allowed 12 fingerboard strings to be strung and about 60 cm string length on the fingerboard was the 14-string Liuto attiorbato. Although this instrument traditionally had only 7 fingerboard courses, its lower pegbox was so wide due to the neck construction that its left side could be cut out without any problems – as is usual with the Angélique – in order to make room for additional fingerboard strings. The double-stringed bridge of the instrument initially remained the old one, only the upper string of each course was omitted and the original G tuning of the Liuto attiorbato was transformed into a modified D minor tuning. Such a stringed instrument is the only one of all lute models available at that time that allows the correct reproduction of BWV 996 and 1006a (with scordatura).

By 1727 at the latest, Johann Sebastian Bach’s lute, equipped with only 14 single strings, seems to have undergone a modification in Leipzig. BWV 995, 997 and 998 written after 1727 require a 16-string instrument with 10 fingerboard strings and 6 bourdon strings, i.e. the classical string arrangement of an angélique. This suggests the suspicion that the client for BWV 995, 997 and 998 was a player of such an instrument, but did not use it in the diatonic tuning of an angélique, instead in the modified D minor tuning with single strings mentioned above. The 16th string, which was “surplus” in this tuning, was used for a tone which was outside the tuning of the bass strings of the instrument according to the key. BWV 995 and 997 are the note E (in addition to the regular bass string in E-flat), which occurs only once in BWV 995 (Sarabande) and twice in BWV 997 (Double). For BWV 998 this additional 16 string was tuned down to D flat and used only once in the whole piece (Allegro). These altered bass tones sound highly attractive at the relevant passages, were deliberately composed in; if transposed an octave higher, not only would Bach’s flawless voice-leading be falsified, but these notes would also lose much of their effect. A historical parallel to this type of tuning is probably the 15 course D minor lute by Jonas Elg (1728) at the “Musikhistoriska Museet” in Stockholm. The fourteenth and fifteenth courses were most likely tuned to E-flat (D sharp) and C sharp (D flat). The instrument may be associated with two anonymous 18th century lute suites in E-flat minor and A flat major, in which these altered tones are obviously also an essential part of the composition and thus indispensable.

So that Bach’s compositions for the 14-string instrument with 12 fingerboard strings as well as those for the model with swan neck and only 10 fingerboard strings can be reproduced on the same instrument, our 16-string Bach lute has 12 pegs in the first and 6 in the second pegbox of the swan neck. This opens the possibility to use all Bach-tunings for the correct reproduction of Bach’s lute works on the same instrument.

See also: http://www.bach-lautenwerke.de/en.html

Picture: Angélique by Johann Christoph Fleischer, Hamburg o.J.,
Landesbibliothek Mecklenburg-Vorpommern (Schwerin)
Source: Fotodesign Klose, Schwerin

Picture: Liuto attiorbato, 17. Jhd., original neck,
Source: https://de.wikipedia.org/wiki/Erzlaute

Samples

Please note that when recording with Liuti forti, there is no difference between the sound of the instrument in the recording and the sound of the instrument in the original. If you wish, compare the sound of the respective pieces with recordings of the same piece on copies of historical lutes that can be found on the Internet.

Johann Sebastian Bach „Gavotta“ g minor from BWV 995
Oliver Holzenburg, Swizzerland
Liuto forte in d („Bach-Lute“)
